Craftsman Style Apartment Garage

Ruby Grace - 29357

1001
Sq Ft
1
Beds
1
Baths
3
Bays
39' 0"
Wide
33' 0"
Deep

Floor Plan Images

Main Level

Traditional Style Apartment Garage | Ruby Grace

Second Level

Traditional Style Apartment Garage | Ruby Grace

Plan Description

Craftsman styling, low pitched roof, thinset stone veneer, and two-tone siding help set this 3 car apartment garage apart from its competition. When pulling into your 3 car garage you will be greeted with ample room for your daily driver at 28' in depth. A formal entry with staircase sits behind the garage which leads you upstairs to your 1 bedroom apartment.  A kitchen with all the amenities which are found in a much larger home sits at the top of the stairs. The kitchen hosts an island for entertaining guest as well as a walk-in pantry.  The oversized dining and family room are nestled next to the kitchen.  The master bedroom lies just off of the family room and it hosts a tray ceiling,  walk-in closet with laundry and a 3/4 bath.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Layout
Bedrooms 1
Bathrooms 1
Garage Bays 3
Square Footage
Second Level 1001 Sq. Ft.
Garage 1170 Sq. Ft.
Total Finished Area 1001 Sq. Ft.
Exterior Dimensions
Width 39 ' 0"
Depth 33 ' 0"
Ridge Height
Calculated from main floor line
24 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Slab
Exterior Wall Construction
2x4
Roof Pitches
6/12 Primary
Main Wall Height
10'
Second Wall Height
8'
