Modern Cottage Style House Plan

Olive Flats - 30390

4990
Sq Ft
5
Beds
5
Baths
4
Bays
120' 4"
Wide
107' 4"
Deep

Plan Video

Floor Plan Images

Main Level

Olive Flats

Second Level

Olive Flats

Plan Description

Explore the Olive Flats, a luxurious, modern cottage-style house that effortlessly blends elegance, comfort, and functionality. This exquisite home plan features five spacious bedrooms, each designed as a private sanctuary filled with natural light, and five luxurious bathrooms. The four-car garage provides ample space for your vehicles and additional storage, ensuring convenience and style.

The floor plan promotes open-concept living with a seamless flow between the kitchen, dining, and living areas, enhanced by high ceilings and large windows that create a bright, airy atmosphere and showcase beautiful views of the surrounding landscape. In the heart of the home is an expansive, state-of-the-art kitchen with a generous island for meal prep and casual dining, as well as plenty of storage, making it perfect for both everyday cooking and entertaining guests.

The expansive outdoor living areas around the home are designed for both relaxation and entertainment. These spaces are perfect for hosting gatherings or enjoying a quiet evening outside.

 The Olive Flats is a modern cottage-style house plan that is the perfect blend of luxury and comfort, designed to create lasting memories and provide a cozy, upscale lifestyle.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Layout
Bedrooms 5
Bathrooms 5
Garage Bays 4
Square Footage
Main Level 4175 Sq. Ft.
Second Level 815 Sq. Ft.
Covered Area 957 Sq. Ft.
Garage 1669 Sq. Ft.
Total Finished Area 4990 Sq. Ft.
Exterior Dimensions
Width 120 ' 4"
Depth 107 ' 4"
Ridge Height
Calculated from main floor line
32 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Slab
Exterior Wall Construction
2x6
Roof Pitches
Primary 10/12, Secondary 14/12, Secondary 8/12, Secondary 6/12
Main Wall Height
10'
Second Wall Height
8'

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
