Traditional Style House Plan

Oakville - 30111

Sq Ft
58' 8"
74' 0"

Plan Video

Floor Plan Images

Main Level


Second Level


Plan Description

The Oakville is a stunning traditional style home. The exterior symmetry lends itself to elements of the Colonial style. A front covered stoop leads into a 2 story entry way. To the left of the entry, you'll find a large formal living room. To the right of the entry, you'll find a formal dining room with a hallway to the kitchen.

The kitchen, great room, and dinette flow seamlessly in an open layout. The great room lies under a 2 story ceiling and is warmed by a fireplace. A built-in bookshelf is next to the fireplace. The kitchen includes a large island with a snack bar and a massive walk-in pantry.

The amazing master suite is located on the left side of the home. The large master bedroom lies under a decorative trayed ceiling and a private door leads to the rear patio. The master bathroom features a large soaking tub, a walk-in shower, an enclosed toilet area, and a large walk-in closet.

On the second floor, you'll find 4 additional bedrooms and a large family room. the family room shares a centrally located hall bathroom with bedroom 5. Bedroom 4 has its own bathroom while bedrooms 2 and 3 share a Jack and Jill bathroom.

Back on the main level, the homes huge 3 car side load garage accesses the home through a mud room with a bench and lockers.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.
