1 Story Multi-Family Traditional House Plan

McGrath - 29381

Sq Ft
Per Unit
Per Unit
Per Unit
Per Unit
100' 0"
53' 0"

Floor Plan Images

Main Level

1 Story Multi-Family Traditional House Plan | McGrath

Plan Description

A tasteful balance of gables dress the front of this attractive one-story, multi-family house plan. A few steps inside the entry, and immediately inside from the 2-car garage, a handy area with bench and lockers helps to contain clutter. A sensibly placed coat closet lies nearby, across the entry.

Interior views soon unfold to reveal an open arrangement between the great room, breakfast area and kitchen. This entire area of the home is brightened by plenty of natural light, while the great room's fireplace provides cozy comfort. The kitchen enjoys ample counter space, an angled work island and a walk-in pantry.

The master suite, situated for maximum privacy, features a pampering bath area with his and her vanities flanking an angled soaking tub, shower, compartmented toilet and a sizeable walk-in closet. Bedrooms 2 and 3 share a centrally located hall bath. A nearby laundry area with counter space for folding clothes is located to serve all bedrooms.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 3
Per Unit
Bathrooms 2
Per Unit
Garage Bays 2
Per Unit
Square Footage
Main Level 1889 Sq. Ft.
Per Unit
Garage 446 Sq. Ft.
Per Unit
Total Finished Area 1889 Sq. Ft.
Per Unit
Exterior Dimensions
Width 100 ' 0"
Depth 53 ' 0"
Ridge Height
Calculated from main floor line
25 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
8/12 Primary, 4/12 Secondary
Foundation Wall Height
Main Wall Height
