29854 | Catarina

Estimated Cost to Build
$88,000 to $106,000
View Cost Assumptions
Powered by:

1.5 Story

3517 Sq. Ft.

4 Beds

4 Baths

3 Car
Get this plan today for only
Click here to view options.
Did you know you can make alterations to this plan?

Floor Plans

Catarina Floor PlanCatarina Floor Plan

Optional Finished Basement

Catarina Floor Plan

Plan Description

The Catarina plan is a modern Mediterranean style masterpiece. The exterior of this plan is sure to leave anyone that passes by speechless. Classic Mediterranean stylings, mixed with some modern accent pieces give this house a unique facade. Much like the exterior of the home, Catarina's interior is sure to impress with its creative floor plan. A grand entry greets guests with its double-sided fireplace that is shared with the great room. Just off the entry to the right, you'll find a stunning den that brings in a ton of natural light with its large windows. Much like the den, the great room also lets in a ton of light with 6 sets of french doors. The kitchen lies under a decorative ceiling with exposed wood beams and features a large island with a prep sink and a walk-in pantry.  Also on the main floor for ultimate convenience, the master suite lies under its own decorative ceiling and features a large bathroom. The master bath includes a soaking tub, enclosed toilet, his/her vanities, and an amazing walk-in shower that is accessible from the outside to make it easier to wash up after using your hot tub in the amazing courtyard.

Upstairs, you will find 3 additional bedrooms and a wonderful family room. The family room has a trayed ceiling and is warmed by a fireplace. A study with a built-in desk is a perfect place to get work done. Bedroom 4 shares a bathroom with the family room while bedroom 2 and 3 share a bathroom. A deck is accessible from the family room.

Back on the main level, the home's large 3 car side-load garage accesses the home through a convenient mudroom with a bench and lockers.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at Ahp.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Full Specifications


Bedrooms 4
Bathrooms 4
Car Bays 3


Main 2360 Sq. Ft.
Second 1157 Sq. Ft.
Total Finished 3517 Sq. Ft.
Garage Area 877 Sq. Ft.


Width 93'
Depth 72'


Foundation Type Basement
Exterior Walls 2x4
Roof Pitch 6/12 Primary
Basement Wall Height 9'
Main Wall Height 9'
Second Wall Height 8'

Plan Features

What is included in a set of plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell. Depending on the home designer there might be more home building information provided.

Our blueprints include:

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical stair section
  • Cabinets are shown on all plans.
