29827 | Oak Hills

Print Book Page
Price Match Guarantee
Available Options
Do you need to get this house bid out before you buy the plan? Purchase a bid set for only $500.

renderingImages[0]; ?>
Actual Customer Build Photos May Not Match The Plan Exactly.
Did you know you can make alterations to this plan?
1604 Sq ft.
2 Beds
2 Baths
3 Car
54' 0" Wide
50' 0" Deep
What do you think?

Floor Plans

Plan Description

Whether you are looking for a guest house or a place to park your RV, the Oak Hills is the perfect plan for you. The modern farmhouse exterior gives this apartment garage a wonderful curb appeal. On the main level, you'll find a 2 car garage and a pull through RV garage. Also on the main floor is a mud room that has a bench and lockers for storage. On the upper level of this garage, you will find an efficient apartment that has a full kitchen. The kitchen includes an island with a flush snack bar. Enjoy your outdoor space with a large balcony off of the front of the apartment.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Similar Plans

Millard Heights

If you are looking for a carriage house that will give you a unique blend of textures, look no further than the Millard Heights plan. A mixture of stone, siding, and wood gives this garage a modern rustic feel. On the main level, you find a 2 car garage that includes a workshop with a built- ...read more

Chesapeake Bay

If you are looking for some extra parking space and a place for the family to stay, the Chesapeake Bay is the perfect plan for you. The classic brick exterior gives this apartment garage a trad ...read more

Timber Valley

The Timber Valley is a modern carriage house plan that has excellent curb appeal. The exterior features a mixture of wood, stone, and glass. The main floor has 3 garage bays and a bathroom. Upstairs there is a full apartment that includes a full kitchen and 2 bedrooms.

...read more

Full Plan Specs


Bedrooms 2
Bathrooms 2
Garage Bays 3

Square Footage

Main Level 430 Sq. Ft.
Second Level 1174 Sq. Ft.
Garage 1554 Sq. Ft.
Total Finished 1604 Sq. Ft.

Exterior Dimensions

Width 54' - 0"
Depth 50' - 0"
Ridge Height 28' - 0"
Ridge height shown from main level floor line.

Construction Specs

Foundation Type Slab
Exterior Walls 2x4
Roof Pitches 6/12 Primary, 10/12 Secondary
Main Wall Height 9'
Second Wall Height 9'
