29316 | McCollum


Multi-Family

689 Sq. Ft.

1 Beds

1 Baths

2 Car

Floor Plans

McCollum Floor PlanMcCollum Floor Plan

Plan Description

This loft apartment, multi-family house plan has a decidedly French Country appeal, created by sloping roof lines and an array of windows perched above a quartet of garage doors. Inside, guests are greeted by views of the great room and kitchen, which lie open to one another. The kitchen is smartly designed for efficiency and includes a practical breakfast bar. An alcove off the great room leads to the master bedroom, laundry room, and full bath.

Full Specifications

Area

Second 689 Sq. Ft.
Total Finished 689 Sq. Ft.
Garage Area 573 Sq. Ft.

Dimensions

Width 52'
Depth 26'
Ridge Height 29'

Construction

Foundation Type Slab
Exterior Walls 2x4
Roof Pitch 8/12 Primary, 10/12 Secondary
Main Wall Height 9'
Second Wall Height 9'

Plan Features


What is included in a set of plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell. Depending on the home designer there might be more home building information provided.

Our blueprints include:

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical stair section
  • Cabinets are shown on all plans.

29316 | McCollum

$1200
Do you need to get this plan bid out before you buy it? Purchase a bid set for only $250 .
