Advanced House Plans

29054 | Mayberry


Split Level

1354 Sq. Ft.

3 Beds

2 Baths

2 Car
Get this plan today for only
$800.00
Click here to view options.
Did you know you can make alterations to this plan?

Floor Plans

Mayberry Floor PlanMayberry Floor Plan

Plan Description

The Mayberry is a split level traditional house plan with a family room on the lower level, and cathedral ceilings on the 2nd floor in the living room area. There is also a deck off the dining room and a 469 sq. ft. 2 car garage.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at Ahp.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Full Specifications

Rooms

Bedrooms 3
Bathrooms 2
Car Bays 2

Area

Basement 258 Sq. Ft.
Main 1096 Sq. Ft.
Total Finished 1354 Sq. Ft.
Garage Area 469 Sq. Ft.

Dimensions

Width 42'
Depth 27'
Ridge Height 19'

Construction

Foundation Type Basement
Exterior Walls 2x4
Roof Pitch 8/12 Primary, 10/12 Secondary
Basement Wall Height 8'
Main Wall Height 8'

Plan Features


What is included in a set of plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell. Depending on the home designer there might be more home building information provided.

Our blueprints include:

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical stair section
  • Cabinets are shown on all plans.

29054 | Mayberry

$800
Do you need to get this plan bid out before you buy it? Purchase a bid set for only $250 .
