Want to make changes to this plan?

Barndominium Style House Plan

Fitchburg - 30349

Sq Ft
54' 0"
67' 0"

Plan Video

Floor Plan Images

Main Level


Second Level


Plan Description

Welcome to the Barndominium Carriage House, a stunning and versatile living space that seamlessly blends the rustic charm of a barn with the modern comforts of a home. This two-story structure offers a spacious and functional layout, designed to accommodate both your living needs and storage requirements.

As you enter the Carriage House, you are greeted by a bench and locker drop zone. There is a convenient bathroom for your comfort and a concrete safe room, offering peace of mind during severe weather or emergency situations. There is a large garage on the main floor, providing ample space to house your vehicles, recreational equipment, or serve as a workshop.

Ascending the staircase to the upper level, you'll find yourself in the heart of the homeā€”an open and inviting great room that combines the living, kitchen, and dining areas into a single expansive space. This open concept design allows for seamless interaction and easy entertaining, making it the perfect gathering place for family and friends.

The kitchen is thoughtfully designed with modern appliances, ample counter space, and a functional island, ensuring that every culinary endeavor is a delight.

This Barndominium Carriage House features three bedrooms, each offering a private sanctuary for rest and relaxation. The master bedroom boasts its own luxurious bathroom, complete with a walk-in shower, soaking tub, elegant fixtures, and a spacious walk-in closet, providing a tranquil retreat within the home. The other two bedrooms are located on the opposite side of the house and share a well-appointed hall bathroom, ensuring privacy and convenience for all occupants.

Throughout the Carriage House, you will find a harmonious blend of rustic elements and modern finishes. Large windows flood the space with natural light, creating a warm and inviting atmosphere.

Outside, the Barndominium Carriage House showcases its distinctive barn-inspired aesthetic, with a combination of board and batten siding and charming architectural details. The property offers ample outdoor space for relaxation and recreation, including the potential for a picturesque patio or garden area.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 3
Bathrooms 3
Garage Bays 4
Square Footage
Main Level 282 Sq. Ft.
Second Level 2287 Sq. Ft.
Covered Area 981 Sq. Ft.
Garage 2054 Sq. Ft.
Total Finished Area 2569 Sq. Ft.
Exterior Dimensions
Width 54 ' 0"
Depth 67 ' 0"
Ridge Height
Calculated from main floor line
32 ' 8"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
Primary 6/12, Secondary 3/12, 4/12
Main Wall Height
Second Wall Height

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
