Ultra Modern Farmhouse Ranch Plan

Broadmoor - 29928

Sq Ft
71' 0"
80' 0"

Plan Video

Floor Plan Images

Main Level


Optional Finished Basement


Plan Description

The Broadmoor is an ultra-modern farmhouse plan. White stucco provides a stark contrast with the black metal roof with zero overhangs. Three separate outdoor spaces make this home perfect for outdoor entertainment. On the front of the house, there is a large covered porch under a built-in pergola. On the side of the house, you'll find a large covered courtyard with its own pergola. On the rear of the house, you'll find a large covered patio that is perfect for grilling.

One step inside the home, you'll be blown away by the large entry with its exposed beams. The great room and dining room flow in an open floor plan and lie under a soaring cathedral ceiling. The home's beautiful kitchen includes a large walk-in pantry and a large island. An atrium off the rear of the living room leads down to the optional finished basement. The master suite lies under its own cathedral ceiling and includes a soaking tub, his/her vanities, and a large walk-in closet with laundry room access. A second bedroom on the main floor has access to its own bathroom.

An optional finished basement can add 1878 sq ft to the home and includes 2 additional bedrooms, a family room, a rec area, and a stunning wet bar with a wine cellar.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 2
Bathrooms 3
Garage Bays 3
Square Footage
Main Level 2546 Sq. Ft.
Garage 1084 Sq. Ft.
Total Finished Area 2546 Sq. Ft.
Exterior Dimensions
Width 71 ' 0"
Depth 80 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
6/12 Primary, 12/12 Secondary
Foundation Wall Height
Main Wall Height

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
