Modern Cottage Style House Plan

Barrett Park - 30398

Sq Ft
115' 0"
65' 4"

Plan Video

Floor Plan Images

Main Level

Barrett Park

Plan Description

Introducing a modern cottage plan designed for comfort, functionality, and stylish living. This single-story residence boasts a striking exterior with clean lines and contemporary elements, blending seamlessly with its natural surroundings.

As you approach, the focal point is the spacious three-car garage, with one stall specifically designed to accommodate an RV, providing convenience and versatility for outdoor enthusiasts. The garage doors are sleek and modern, complementing the overall aesthetic of the home.

Upon entering the main living area, you are greeted by an expansive open floor plan that seamlessly integrates the kitchen, dining area, and great room, creating an inviting space for gatherings and relaxation. Large windows flood the area with natural light, enhancing the sense of openness and connection to the outdoors.

The kitchen is a chef's dream, featuring ample counter space, high-end appliances, and a large center island perfect for meal preparation and casual dining. A standout feature is the arched window above the sink, framing picturesque views and adding architectural interest to the space. The cathedral ceiling with exposed wood trusses adds warmth and character, creating a cozy atmosphere that invites lingering conversations and culinary adventures.

The cottage offers three bedrooms, each thoughtfully designed to provide comfort and privacy for residents and guests alike. The master suite boasts a luxurious ensuite bathroom and direct access to one of the covered porches, offering a serene retreat to unwind and enjoy the surrounding landscape.

Outside, three covered porches wrap around the home, providing ample opportunities for outdoor living and entertaining. Whether sipping morning coffee, hosting a barbecue with friends, or simply enjoying the fresh air, these versatile spaces enhance the connection between indoor and outdoor living, inviting residents to embrace the beauty of nature year-round.

Overall, this modern cottage plan offers a harmonious blend of style, functionality, and comfort, providing the perfect backdrop for creating cherished memories and embracing the art of living well.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 3
Bathrooms 3
Garage Bays 3
Square Footage
Main Level 3164 Sq. Ft.
Covered Area 561 Sq. Ft.
Garage 1192 Sq. Ft.
Total Finished Area 3164 Sq. Ft.
Exterior Dimensions
Width 115 ' 0"
Depth 65 ' 4"
Ridge Height
Calculated from main floor line
26 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
Primary 10/12, Secondary 14/12, 6/12
Main Wall Height

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
