Advanced House Plans

29413 | Richmond


1 Story

2270 Sq. Ft.

3 Beds

2 Baths

3 Car
Get this plan today for only
$1000.00
Click here to view options.
Did you know you can make alterations to this plan?

Floor Plans

Richmond Floor Plan

Plan Description

A blend of stucco and stone enhance the exterior of this Mediterranean style 1-story house plan.  Inside, guests are welcomed by a high entry that opens to an over-sized great room with tall ceilings and a fireplace flanked by bookcases.  The kitchen, with its pantry and island work station, adjoins the dining area, which opens onto a rear covered patio, where guests can mingle before dinner is served.

On the opposite side of the first floor, a generously sized master suite is tucked away for privacy.  The well-appointed master bath includes a large tub, walk-in shower, compartmented toilet and walk-in closet.  Bedroom 2 enjoys a walk-in closet and shares a hall bath.  The Flex room can be used as a bedroom #3 or an office and is conveniently located next to the entry.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at Ahp.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Full Specifications

Rooms

Bedrooms 3
Bathrooms 2
Car Bays 3

Area

Main 2270 Sq. Ft.
Total Finished 2270 Sq. Ft.
Garage Area 931 Sq. Ft.

Dimensions

Width 73'
Depth 75'
Ridge Height 21'

Construction

Foundation Type Basement
Exterior Walls 2x4
Roof Pitch 6/12
Basement Wall Height 9'
Main Wall Height 9'

Plan Features


What is included in a set of plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell. Depending on the home designer there might be more home building information provided.

Our blueprints include:

  • Cover Sheet: Shows the front elevation and typical notes and requirements.
  • Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
  • Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
  • Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible
  • Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
  • Roof Plan
  • Typical wall section
  • Typical stair section
  • Cabinets are shown on all plans.

29413 | Richmond

$1000
Do you need to get this plan bid out before you buy it? Purchase a bid set for only $250 .
